22
Step 1 Wrap the power adapter cable through the plastic security clip as shown in Figure 11.
Figure 11 Plastic Relief Clip
Step 2 Fasten the security clip with a screw to the existing hole on the back panel on the 2504
controller (see
Figure 12).
Figure 12 Securing the Power Adapter Cable
281917
281918
1
3
2
