Connecting ATM Network Modules to a Network 12-3
Connecting ATM-25 Ports to the Network
Figure 12-2 Connecting the ATM-25 Module to an ADSL Modem
ATM
25MbPS
ATM 0
TX
EN
RX
11707
ADSL modem
Straight-through
RJ-45-to-RJ-45 cable
ATM-25 port
(RJ-45)
