Flexible power options: The camera supports Power over Ethernet (PoE+) 802.3at, High PoE, or 24 VAC power
through an external power supply.
Simple Web Interface: The Cisco Video Surveillance 2800 Series supports Internet Explorer 8.0 for remote setup
and administration.
Privacy Masking: Privacy masking is used to conceal user-defined privacy areas that cannot be viewed by an
operator. The Cisco Video Surveillance 2800 Series supports up to four privacy masked regions. A masked area
will appear on the screen as a solid, or user defined colored window.
Product Specifications
Table 1 lists the product specifications for the Cisco Video Surveillance 2800 Series.
Table 1. Product Specifications
General
Available Languages English
Supported Protocols TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, SNMP, QoS, HTTP,
HTTPS, LDAP (client), SSH, SSL, SMTP, FTP, mDNS (Bonjour)
Security Access Password-protected
Certifications/Ratings/Patents CE, Class A
FCC, Class A
UL/cUL Listed
C-Tick
Signal Format NTSC (CIVS-IPC-2830)
PAL (CIVS-IPC-2835)
Scanning System Progressive
Image Sensor 1/4-inch CCD
Lens 3.7 to 44 mm
Zoom 12x optical
12x digital
PTZ Speed Pan speed: 0.05° to 450°/sec
Tilt speed: 0.05° to 450°/sec
Horizontal
Angle of View
56.3° (W) to 4.6° (T)
Minimum Illumination Color:
0.9 lux @1/60 sec (NTSC), 1/50 sec (PAL)
(F1.4, 50IRE)
0.05 lux @1/4 sec (NTSC), 1/3 sec (PAL)
B/W:
0.01 lux @ 1/4 sec (NTSC), 1/3 sec (PAL)
White Balance Automatic with manual override
Shutter Speed 1/4 sec to 1/10000 sec (20 steps) NTSC
1/3 sec to 1/10000 sec (20 steps) PAL
Electronic
Iris Control Automatic, with manual override
Gain Control Automatic/OFF
Wide Dynamic Range TBD
Motion Detection Integrated
