Cisco 2800 Series Datasheet

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 5
Electrical
Ports RJ-45 connector for 100BASE-TX
Cabling Type Cat5 or better for 100BASE-TX
Input Power AC: 28W (-40 to 55’C)
PoE+: 18W (-5 to 55’C)
High PoE: 28W (-40 to 55’C)
Alarm Inputs 4
Auxiliary Outputs 2
Pan Movement 360° continuous pan rotation
Vertical Tilt 220° (+20° above horizon)
Audio
Streaming Bidirectional; full- or half-duplex
Input/Output Terminal connector
Compression G.711 A-Law, G.711 U-Law
Video
Video Encoding H.264 and MJPEG
Video Streaming
●
Single-stream H.264 or MJPEG up to 720 x 480 @ 30 fps (720 x 576 @ 25 fps)
●
Dual-stream H.264 and MJPEG
◦ Primary stream programmable up to720 x 480 @ 30 fps (720 x 576 @ 25 fps)
◦ Secondary stream programmable up to 720 x 480 @15 fps (720 x 576 @ 15 fps)
Resolution and Frame Rate
(H.264)
Refer to Table 2
Resolution and Frame Rate
(MJPEG)
Refer to Table 2
Weight 3.3 Kg
Operating Temperature AC 24V: -40 to 55°C
PoE+: -5 to 55°C
High PoE: -40 to 55°C
Outdoor Rating IP66 when installed properly
Table 2 lists the video stream support for the Cisco Video Surveillance 2800 Series for 4:3 aspect ratios.
Table 2. Video Stream Support for 4:3 Aspect Ratios
Primary (H.264) Maximum fps Secondary (H.264 or MJPEG) Maximum fps
720 x 480/576 30/25 720 x 480/576
352 x 240/288
15
704 x 480/576 30/25 704 x 480/576
352 x 240/288
15
352 x 240/288 30/25 352 x 240/288 15
Software
Table 3 describes the primary features of Cisco Video Surveillance 2800 Series IP Camera software.
Table 3. Primary Software Features
Item Specification
Activity Detection User-definable alerts with configurable sensitivities and thresholds, email alert, and HTTP notifications
Video Format NTSC and PAL
Image Settings White balance, automatic exposure, noise reduction, wide dynamic range, exposure compensation
