Cisco 3200 Series User Manual

2-19
Cisco 3200 Series Router Hardware Upgrade Guide
OL-15983-01
Chapter 2 Replacing Cards in the Cisco 3230 ISR Rugged Enclosure
Card Replacement Process
Reattaching the Antenna End Cap
To reattach the antenna end cap, follow these steps:
Step 1 If you have added one or more WMICs, remove two of the corresponding plugs from the antenna end
cap and replace them with RP-TNC connectors.
Step 2 Attach the antenna cables to the antenna end cap, as shown in Figure 2-2.
Step 3 Attach the identification labels for the antennas to the antenna end cap.
Step 4 Use a 3/8-inch socket wrench to secure the antenna end cap with 4 1/4-20x1.25-inch-long bolts. The
torque range for the antenna end cap bolts are 58 to 68 in-lb.
Applying New I/O End Cap Function Labels
To apply new I/O end cap function labels, follow these steps:
Step 1 Label the WMIC console ports.
Step 2 If you have more than one WMIC installed in the router, remove the W2 plate on the I/O end cap and
replace it with the DB-9 console connector.

Cisco 3200 Series Specifications

General

Connectivity Technology	Wired
QoS Support	Yes
Operating System	Cisco IOS
Routing Protocols	BGP
Security	Firewall, VPN, ACLs
Management	SNMP, Telnet, CLI
Operating Temperature	32 °F - 104 °F
Product Type	Router
Data Link Protocol	Ethernet, Fast Ethernet
Features	VPN support, QoS
Product Family	3200
Category	Routers
LAN Interfaces	Fast Ethernet, Gigabit Ethernet
