Cisco 3745 User Manual

14
Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than:
20A, 60VDC. Statement 1005
Warning Use copper conductors only. Statement 1025
DC Wiring Requirements
A Cisco 3745 router with a DC-input power supply requires copper wire for the power connections. Table 2 summarizes the
wiring requirements.
Wiring Procedure for DC Input
To connect the router to a DC power source, perform the following steps:
Step 1 Remove power from the DC circuit. To ensure that power is removed from the DC circuit, locate the circuit breaker for
the DC circuit, switch the circuit breaker to the OFF position, and tape the circuit-breaker switch in the OFF position.
Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Tip Secure all power cabling when installing this unit to avoid disturbing field-wiring connections.
Step 2 Strip the wires to the appropriate length for the terminals. The strip length is 1/8 to 3/16 inch (3 to 5 mm) for Molex
number 19073-0009 terminals and for AMP/Tyco number 52961 terminals.
Table 2 DC Wiring Requirements for Cisco 3745 Routers
Installed Power Supply DC Input
DC Input Wire
Size
Safety Ground
Wire Size Wire Terminal (Lug)
Overcurrent
Protection
Nominal 24/48 VDC
1
Identified by the following printed
label:
1. The input voltage tolerance limits for nominal 24/48 V power supplies are 18 and 72 VDC.
24 - 36 V, 15 A AWG 12
(3.0 mm
2
)
AWG 12
(3.0 mm
2
),
minimum
Amp/Tyco No.
52961 or equivalent
20 A
maximum
36 - 60 V, 7 A AWG 12 or 14
(3.0 or 2.0 mm
2
)
AWG 12
(3.0 mm
2
),
minimum
For AWG 12:
Amp/Tyco No.
52961 or equivalent
For AWG 14: Molex
No. 19099-0017 or
equivalent
20 A
maximum
Nominal 48 VDC
2
Identified by the following printed
label:
2. The input voltage tolerance limits for nominal 48 V power supplies are 38 and 72 VDC.
48 - 60 V, 10 A AWG 14 or 16
(2.0 or 1.2 mm
2
)
AWG 14
(2.0 mm
2
),
minimum
For AWG 14 or 16:
Molex No.
19099-0017 or
equivalent
20 A
maximum
100-240V 50/60Hz 10A
OR Input +/- 24-36 V 15 A
36-60 V 7 A
!
CISCO 3745
~
100-240V 50/60Hz, 10A
OR 48-60V , 10A
!
CISCO 3745
~

Cisco 3745 Specifications

General

Form Factor	Rack-mountable
Network Module Slots	4
Advanced Integration Module Slots	2
Product Type	Router
Connectivity Technology	Wired
Data Transfer Rate	100 Mbps
Data Link Protocol	Ethernet, Fast Ethernet
Encryption Algorithm	DES, 3DES, AES
Authentication Method	RADIUS, TACACS+
Operating System	Cisco IOS
Power Supply	AC 120/230 V (50/60 Hz)
Operating Temperature	32 to 104 °F (0 to 40 °C)
Storage Temperature	-4 to 149 °F (-20 to 65 °C)
Interfaces	10/100 Ethernet
RAM	256 MB
Flash Memory	128 MB (max)
Dimensions	17.5 inches
Network / Transport Protocol	TCP/IP
Remote Management Protocol	SNMP, Telnet, HTTP
Humidity	10% to 85% non-condensing
Processor	Motorola PowerPC
