Figure 3: Figure A-1 Console Port to PC - Cable and Adapter
Table 6: Console Port to PC—Cable Pinouts (RJ-45 to DB-9)
PC Port
(DTE,
DB-9)
RJ-45-to-DB-9
Adapter “TERMINAL”
RJ-45-to-RJ-45
Rollover Cable
Console
Port
(DCE, RJ-45)
SignalDB-9
Pin
RJ-45 PinRJ-45 PinRJ-45 PinSignal
CTS8881
2
RTS
DSR6772DTR
RxD2663TxD
GND5554GND
GND5445GND
TxD3336RxD
DTR4227DSR
RTS71181CTS
2
Pin 1 is connected to pin 8 inside the Cisco VG450 Voice Gateway.
Console Port to ASCII Terminal
Figure A-2 shows the RJ-45-to-RJ-45 rollover cable assembly and the RJ-45-to-DB-25 female DTE adapter
(labeled TERMINAL); Table A-2 lists the pinouts.
Figure 4: Console Port to ASCII Terminal—Cable and Adapter
Cisco 450 Voice Gateway Hardware Installation Guide
30
Cable Specifications and Information
Console Port to ASCII Terminal
