Cisco 4742HDC User Manual

2
What’s In The Carton?
The set-top carton contains the following items:
Additional Equipment You Might Need
You might need some of the cables and adapters shown below for connecting the set-top to your home entertainment
devices. See the connection information in the Connection Diagrams section for more information.
Check with your service provider for information about acquiring cables or adapters, or you can purchase cables or
adapters at your local electronics supplier.
Component Video
Cables (YPbPr)
Audio Left/Right
Cable
• Power Cord
HDMI
Adapter
RGB
Adapter
Optical
Digital
Audio
Cable
IEEE 1394
4-Pin to
4-Pin Cable
• HDC High-De nition Set-Top with M-Card
RF Coaxial
Cable
Coaxial Digital
Audio Cable
S-Video
Cable
• HDMI Cable
HDMI-to-DVI
Cable
IR Extender
Cable
Composite
A/V Cables
RGB Adapter
Cable
(RCA to RCA)
RGB Adapter
Cable
(RCA to VGA)
RGB Adapter
Cable
(RCA to BNC)
• Quick Reference
Guide
Cisco Explorer 4700 Family High-De nition Set-Tops
with Multi-Stream
CableCARD Interface
Quick Reference Guide
4742HDC
4742HDC

Cisco 4742HDC Specifications

General

Model	4742HDC
Category	Set-top boxes
Video Output	HDMI, Component, Composite
Resolution	Up to 1080p
Network	Ethernet
USB	Yes
Power Consumption	15W (typical)
Audio Output	HDMI, Optical
