1-5
Catalyst 4948E and Catalyst 4948E-F Switch Installation Guide
OL-21561-02
Chapter 1 Product Overview
Features
RESET switch
(both chassis)
Resets and restarts the switch.
The switch is recessed on chassis front panel and requires a pointed
object to access it.
Fan tray
Catalyst 4948E chassis
The Catalyst 4948E chassis supports one hot-swappable fan tray (part
number WS-X4993=).
Note The fan trays are not interchangeable between the Catalyst 4948E
and the Catalyst
4948E-F chassis.
The fan tray has four variable-speed 12 VDC fans.
The fan tray installs in the rear of the chassis between the two power
supplies.
The fan tray for the Catalyst 4948E (WS-X4993=) is color-coded dark
grey.
A redundant pair of thermal sensors are positioned near the air inlet
(front of the chassis) to monitor the ambient air temperature and control
the fan tray fan speed.
The airflow in the Catalyst 4948E chassis is from front to back.
The chassis has a FAN LED (located on the chassis front panel) that
provides fan tray status.
Red—One or more individual fans in the fan tray have failed.
Green—All fans in the fan tray are operating normally.
Catalyst 4948E-F chassis The Catalyst 4948E-F chassis supports one hot-swappable fan tray (part
number WS-X4993-F=).
Note The fan trays are not interchangeable between the Catalyst 4948E
and the Catalyst
4948E-F chassis.
The fan tray has four variable-speed 12 VDC fans.
The fan tray installs in the rear of the chassis between the two power
supplies.
The fan tray for the Catalyst 4948E-F is color-coded blue.
A redundant pair of thermal sensors are positioned near the air inlet (rear
of the chassis) to monitor the ambient air temperature and control the fan
tray fan speed.
The airflow in the Catalyst 4948E-F chassis is from back to front.
The chassis has a FAN LED (located on the chassis front panel) that
provides fan tray status.
Red—One or more individual fans in the fan tray have failed.
Green—All fans in the fan tray are operating normally.
Table 1-1 Catalyst 4948E and Catalyst 4948E-F Switch Features (continued)
Feature Description
