© 2012-2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 5
Features and Benefits
Resolutions of 1080p and 720p on a premium 32-inch screen help ensure telepresence is clear and
natural.
The specially designed, high-quality camera provides high-definition (HD) images, with excellent eye
contact; the camera auto-retracts when not in a call, leaving the full screen available for multipurpose use.
Full-duplex, CD-quality audio provides a rich audio experience with no perceivable latency and no
interference from mobile devices or cell phones.
An advanced two-dimensional microphone array allows for additional audio clarity; you can also add a
privacy headset.
You can use the system when not in a telepresence call as a secondary PC monitor or for video output for
digital signage.
The system offers the ability to share content up to 30 frames per second.
Integrated lighting eliminates facial shadows and provides natural-looking video.
Flexible deployment options include a choice of pedestal, tabletop, or custom mounted scenarios.
The pedestal configuration can swivel the display +/-15 degrees and is height-adjustable from 52 to 63
inches.
Simple one-button-to-push calling integrates with common calendaring programs.
The presentation-in-picture feature enables easy content sharing; a connector is available for adding a
dedicated auxiliary display.
Integration with the network helps ensure reliability with high availability, security, and quality of service
(QoS) for an optimal experience; highly secure communications are enabled through encryption of both
video and call signaling.
The system supports any-to-any interoperability with standard- and high-definition videoconferencing
endpoints, and collaboration with desktop video applications, such as Cisco WebEx
®
meeting applications
and the Cisco
®
Digital Media System.
The system includes a Cisco TelePresence Touch 12-inch control device, providing an intuitive user
interface for scheduled calls and access to contacts and directories.
Product Specifications
Tables 1 to 3 list specifications for the Cisco TelePresence 500 Series.
Table 1. Product Specifications
Specification Description
Product compatibility
Cisco Unified Communications Manager 7.1.5 or later
Cisco TelePresence Multipoint Switch 1.6 or later
Cisco TelePresence Manager 1.7 or later
Software compatibility Cisco TelePresence System Software Version 1.7.1.1 or later
User interface Cisco Unified IP Phone 7975G or Cisco Touch 12 (requires Cisco TelePresence Systems Software Version
1.8 or later)
Cisco TelePresence HDC High-
Definition Camera
CMOS 1/3-in. sensor
CS-mount lens
Resolution: 1080p 30
Minimum illumination 300 lux
