4-9
ASA 5505 Getting Started Guide
78-18003-02
Chapter 4 Installing the ASA 5505
Ports and LEDs
Step 1 Plug one end (DB9) of the PC terminal adapter into a standard 9-pin PC serial port
on your PC.
Step 2 Plug the other end (RJ-45) of the blue console cable into the console port.
Step 3 Configure the PC terminal emulation software or terminal for 9600 baud, 8 data
bits, no parity, and 1 stop bit.
Installing a Cable Lock
The Cisco ASA 5505 includes a slot that accepts standard desktop cable locks to
provide physical security for small portable equipment, such as a laptop computer.
The cable lock is not included.
To install a cable lock, perform the following steps:
Step 1 Follow the directions from the manufacturer for attaching the other end of the
cable for securing the adaptive security appliance.
Step 2 Attach the cable lock to the lock slot on the back panel of the Cisco ASA 5505.
Ports and LEDs
This section describes the front and rear panels of the ASA 5505. This section
includes the following topics:
• Front Panel Components, page 4-10
• Rear Panel Components, page 4-12
