Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
9 SIM Green /
Yellow (one
green blink
followed by
two yellow
blinks)
SIM in slot 0 is active, SIM in slot 1 is not.
Yellow /
Green (one
yellow blink
followed by
two green
blinks)
SIM in slot 1 is active, SIM in slot 0 is not.
Off / Green
(two green
blinks and
then a pause)
No SIM in slot 0, SIM present in slot 1.
Green / Off
(slow green
blink once
and then a
pause)
SIM is present in slot0, no SIM in slot 1.
Off / Off No SIM present in either slot.
10 Service Green
(Solid)
Service is active and the corresponding LED is lit based
on the service level which is active (2G, 3G, 3.5G, 3.7 G,
LTE).
Off No service.
11 RSSI Green
(solid)
Very strong signal.
Green (three
blinks and
then a long
pause)
Strong signal.
Green (two
blinks and
then a long
pause)
Fair signal.
Green (one
blink and
then a long
pause)
Marginal signal.
Off No signal.
Table 1-36 LED Descriptions (continued)for the Cisco C898EAG-LTE ISR
