1-118
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
Step 2 Press and hold the Reset button until the system status LED begins to flash. Typically, this occurs within
5 seconds.
The router reloads itself after the startup configuration has been replaced with the new customer
configuration.
LEDs
The LEDs are located on the front panel of the router.
• Table 1-42 describes the LEDs for the Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series
ISRs.
• Table 1-43 lists the LED descriptions for the Cisco 866VAE, Cisco 867VAE, Cisco 866VAE-K9, and
Cisco 867VAE-K9 ISRs.
• Table 1-44 lists the LED description for the Cisco 892FSP, Cisco 896VA, Cisco 897VA, and Cisco
898EA ISRs.
• For a description of LEDs for Cisco 860VAE-W-A-K9, Cisco 860VAE-W-E-K9, and Cisco
860VAE-POE-W-A-K9 ISRs models, see the “Cisco 860VAE-W-A-K9, Cisco 860VAE-W-E-K9,
and Cisco 860VAE-POE-W-A-K9 ISRs” section on page 1-40.
Table 1-42 LED Descriptions for the Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series ISRs
LED Color Description 860 Series 880 Series 890 Series
Power OK Green On—DC power is being supplied to the router and the
Cisco IOS software is running.
Blinking—Bootup is in process, or the router is in
Rommon monitor mode.
Off—Power is not supplied to the router.
All models All models All models
Link Status FE0 Green On—Ethernet port is connected.
Blinking—Data is either being received or being
transmitted.
Off—Ethernet port is not connected.
All models All models All models
Link Status FE1
Link Status FE2
Link Status FE3
Link Status FE4 Green On—Ethernet port is connected.
Blinking—Data is either being received or being
transmitted.
Off—Ethernet port is not connected.
— — All models
Link Status FE5
Link Status FE6
Link Status FE7
FE WAN Port
Link Status
Green On—Port is connected.
Blinking—Data is either being received or being
transmitted.
Off—Port is not connected.
861
models
881
models
All models
GE WAN Port
Link Status
Green On—Port is connected.
Blinking—Data is either being received or being
transmitted.
Off—Port is not connected.
— — All models
