1-120
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
xDSL Data Green Blinking—The xDSL interface is either receiving or
transmitting data.
Off—No data is being transmitted or being received.
— 886,
886VA,
887,
887VA,
887VA-M
888
models
896VA,
897VA,
898EA,
897VAB
xDSL ATM Green On—The router is operating in ATM
6
mode.
Off—Not operating in ATM mode.
— 888E —
xDSL EFM Green Blink—The router is operating in EFM
7
mode.
Off—Not operating in EFM mode.
— — 898EA
Data BRI LINK Green On—ISDN D channel is connected. — 887, 888
models
892
models
Data BRI B1 Green Blinking—B1 channel is either receiving or sending data,
or data is passing through ISDN channel 1.
— 887, 888
models
892
models
Data BRI B2 Green Blinking—B2 channel is receiving or sending data, or
data is passing through ISDN channel 2.
— 887, 887V,
888
models
892
models
3G
8
WWAN
9
Green On—Service is established.
Slow Blinking—Searching for service.
Fast Blinking—Data is either being received or being
transmitted.
— 3G models —
3G RSSI
10
Green Off—Low signal strength (lower than -100 dBm).
On—High RSSI (-69 dBm or higher).
Slow Blinking—Low or medium RSSI (-99 to -90 dBm).
Fast Blinking—Medium RSSI (-89 to -70 dBm).
— 3G models —
Amber On—No service. — 3G models —
3G GSM
11
Green On—Service is established.
Off—No service.
— 3G models —
3G CDMA
12
Green On—Service is established.
Off—No service.
— 3G models —
FXO Voice Green On—FXO port is connected.
Blinking—FXO port is either receiving or transmitting
data.
— 881
13
—
BRI Voice LNK Green On—BRI interface is connected. — — —
BRI Voice B1 Green On—BRI B1 channel is connected.
Blinking—BRI B1 channel is either receiving or
transmitting data.
———
Table 1-42 LED Descriptions for the Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series ISRs (continued)
LED Color Description 860 Series 880 Series 890 Series
