Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 810 Series
Supported Cisco Antennas and Cables
The Cisco 819 ISR provides two standard panel-mount TNC connectors to support the 3G antenna and
the diversity and GPS external antenna. The main antenna is used for the primary 3G antenna. The
second can be used as a diversity receive only 3G antenna or GPS antenna that does not require power
supply from the router.
Table 1-13 lists the Cisco 3G antennas that are supported for use on Cisco 819 ISRs.
Table 1-12 SIM Card Slot
Two Internal SIM Card Slots One Internal SIM Card Slot No SIM Card Slot
C819G-U-K9 C819HG-4G-V-K9 C819HG-V-K9
C819G+7-K9 C819G-4G-V-K9 C819HG-S-K9
C819HG-U-K9 C819HG-4G-A-K9 C819G-V-K9
C819HG+7-K9 C819G-4G-A-K9 C819G-S-K9
C819HGW+7-A-A-K9 C819HGW-V-A-K9
C819HGW+7-E-K9 C819HGW-S-A-K9
C819HGW+7-N-K9 C819HG-B-K9
C819HG-4G-G-K9 C819G-B-K9
C819G-4G-G-K9
Table 1-13 Supported Cisco 3G Antennas
Cisco Part Number Antenna Type
Maximum Gain and
Frequency Range Description
3G-ANTM1919D Dipole
omnidirectional
0 dBi
(806–960 MHz)
0 dBi
(1710–2170 MHz)
This is the default antenna with dual faceplate mount.
Multiband faceplate-mounted dipole antenna. For more
information, see Cisco Multiband Swivel Mount Dipole
Antenna (3G-ANTM1919D).
3G-ANTM1916-CM High-gain
ceiling-mount
omnidirectional
1.5 dBi
(806–960 MHz)
2.5 dBi
(1710–2170 MHz)
Multiband ceiling-mounted omnidirectional antenna.
For more information, see Cisco Multiband
Omnidirectional Ceiling Mount Antenna
(3G-ANTM1916-CM).
3G-AE015-R
(Antenna Extension)
Extension base 0.8–6.0 GHz This antenna extension is a base with a 15-foot cable
included for use with a dipole omnidirectional antenna.
For more information, see Cisco Single-Port Antenna
Stand for Multiband TNC Male-Terminated Portable
Antenna (3G-AE015-R).
3G-ANTM-OUT-OM Outdoor
Omnidirectional
+2 dBi
800/900 MHz
+4 dBi
1800/1900/2100
MHz
This is an outdoor low-profile omindirectional mast
antenna. For more information, see Cisco 3G
Omnidirectional Outdoor Antenna
(3G-ANTM-OUT-OM).
