Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 810 Series
Table 1-16 to Table 1-18 list the extension cables for use with 3G, WiFi, and 4G LTE antennas. The
tables include the insertion loss information for the ultra-low-loss (ULL) LMR 400 extension cables.
Table 1-16 Cisco Extension Cables for Use with 3G Antennas
Cisco Product Number Cable Length Insertion Loss Frequency (MHz)
3G-CAB-ULL-20 20 ft (6 m) 1.50 dB max 2100
3G-CAB-ULL-50 50 ft (15 m) 3.50 dB max 2100
3G-CAB-LMR240-25 25 ft (7.5 m) 3.50 dB max 2200
3G-CAB-LMR240-50 50 ft (15 m) 6.90 dB max 2200
3G-CAB-LMR240-75 75 ft (23 m) 10.5 dB max 2200
Table 1-17 Cisco Extension Cables for Use with WiFi Antennas
Cisco Product Number Cable Length Insertion Loss Frequency (MHz)
AIR-CAB005LL-R 5 ft (1.524 m)
(one RP-TNC plug, one
RP-TNC jack)
0.5 dB
0.8 dB
2400
5800
AIR-CAB020LL-R 20 ft (6 m)
(one RP-TNC plug, one
RP-TNC jack)
1.3 dB
2.5 dB
2400
5800
AIR-CAB050LL-R 50 ft (15.24 m)
(one RP-TNC plug, one
RP-TNC jack)
3.4 dB
5.75 dB
2400
5800
Table 1-18 Cisco Extension Cables for Use with 4G LTE Antennas
Cisco Product Number Cable Length
Maximum Insertion
Loss Frequency (MHz) Color Plenum Rated?
1
4G-AE010-R 10 ft (3 m) 1.4 dB at 700 MHz
2.0 dB at 1.9 GHz
2.1 dB at 2.1 GHz
2.3 dB at 2.5 GHz
700 to 2600 MHz Black No
4G-AE015-R 15 ft (4.6 m) 2.3 dB at 700 MHz
3.3 dB at 1.9 GHz
3.7 dB at 2.1 GHz
4.0 dB at 2.5 GHz
700 to 2600 MHz Black No
4G-CAB-LMR240-25 25 ft (7.6 m) 2.1 dB at 700 MHz
4.0 dB at 2.6 GHz
700 to 1000 MHz
1700 to 2600 MHz
Black Yes
