Cisco 890 Series Installation Guide

A-3
Cisco Integrated Services Router Hardware Installation Guide
OL-27407-02
Appendix A Technical Specifications
Cisco 810 Series
Radio Immunity EN301 489-1, EN 301 489-7, and EN301 489-24
Transportation/Storage Conditions
Temperature –40 to158 °F (–40 to 70°C)
Humidity 5–95%
Altitude 4570 m (15,000 ft)
AC Power Adapter
Power Source 100–240 VAC
In-ceiling Plenum No
IP41 No
Extended Shock-vibe No
Maximum Power Consumption 25 W
Maximum Output Power Rating 20 W
Operating Temperature –13 to 140 °F (–25 to 60 °C)
PoE+ Splitter
Power Source PoE+ (IEEE802.3at Class 4)
In-ceiling Plenum Yes
IP41 No
Extended Shock-vibe No
Maximum Power Consumption 25 W
Maximum Output Power Rating 20 W
Operating Temperature –13 to 140 °F (–25 to 60 °C)
Embedded WiFi Antenna
Frequency Range — 2.4–2.5 Ghz
4.9–5.875 Ghz
Peak Gain — 4 dBi (2.4 GHz)
6 dBi (5.875 Ghz)
Voltage Standing Wave Ratio — 2.5:1 maximum for all bands
Nominal Impedance — 50 ohms
1. Routers shipped in People’s Republic of China.
Table A-1 Cisco 812 ISR Specifications (continued)
Description
C812G+7-K9
(3G only)
C812G-CIFI+7-E-K9
C812G-CIFI+7-N-K9
C812G-CIFI-V-A-K9
C812G-CIFI-S-A-K9
(3G + WiFi)

Cisco 890 Series Specifications

General

Product Type	Router
Form Factor	Desktop
USB Ports	1 x USB 2.0
Firewall	Yes
VPN Support	Yes
RAM	256 MB
Wireless	802.11n
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	10 to 85% non-condensing
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol	TCP/IP
Routing Protocol	OSPF, BGP, RIP-1, RIP-2, EIGRP, HSRP, VRRP
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS, SSH
Features	VPN support, firewall protection, Quality of Service (QoS), VLAN support
Encryption Algorithm	AES, 3DES, DES
