2-11
Cisco Integrated Services Router Hardware Installation Guide
Chapter 2 Installing the Router
Installing the Cisco 810 ISR
Figure 2-10 Universal Bracket Installed on the Cisco 812 ISR
Ceiling Grip Clips
Use a ceiling grid clip to mount the router on a suspended ceiling. The ceiling grid clip that you need
depends on the ceiling tiles on your ceiling. There are two types of ceiling grid clips:
• Ceiling Grid Clip, Recessed (AIR-AP-T-RAIL-R)—If your ceiling tiles hang below the ceiling grid,
this clip provides the best fit between the router and the ceiling.
• Ceiling Grid Clip, Flush (AIR-AP-T-RAIL-F)—If your ceiling tiles are flush with the ceiling grid,
this clip provides a snug fit between the router and the ceiling.
The standard 9/16, 15/16, and 1 ½-inch wide T-rail mounting are supported with the Ceiling Grip Clips.
1 Universal bracket
