Appendix A
Field Name
Description
Possible Values
LP Checksum
Link Privacy Checksum value
 [Integer > 0]
Important: For two or more
devices to form a MoCA network,
their LP checksums must match,
when Link Privacy is enabled.
Number of
Nodes
Number nodes present on the
MoCA network, not including
the current node
 [Integer ≥ 1]
The total number of nodes in the
network is the Number of Nodes +
1.
RF Channel
Channel center frequency of
the MoCA network (in MHz)
 Value: 1150 MHz
Note: The RF channel frequency
is 1150 MHz. If it is not, record the
frequency for comparison with
other devices on the network.
NC Node ID
Node ID of the network
coordinator
 [Range: 0 – N] where N = 15 for
MoCA 1.1
DRIVERS - MoCA SUMMARY PG 2A
Field Name
Description
Possible Values
TX Unicast
PHY Rate
(Mbps)
Transmit rate from the local node
to each other node in the
network (in Mbps)
 [Integer > 0]
Note: Minimum value is 200 Mbps,
lower rates require fixing the home
coaxial wiring.
Wait at least 30 seconds after Link
Up is achieved.
Broadcast
PHY Rate
(Mbps)
Broadcast PHY rate of each
remote node (other than this set-
top/node) in the MoCA network
(in Mbps)
 [Integer > 0]
Note: Minimum value is 200 Mbps,
lower rates require fixing the home
coaxial wiring.
DRIVERS - MoCA SUMMARY PG 2B
Field Name
Description
Possible Values
Local Node
Rx Level
(dBm)
Receive level from each other
node to the local node.
 [Integer < 0]
Approx Path
Loss (dB)
Approximate loss from each
node to the local node.
 [Integer > 0]
Important: Losses greater than 50
dB can indicate a problem with the
home wiring. These problems must
be fixed so that the losses are less
than 50 dB.

Cisco 9865HDC Specifications

General

Model	9865HDC
High Definition	Yes
DVR	Yes
Category	Set-top box
Connectivity	Ethernet
Network	Ethernet
Chipset	Broadcom
CPU	Dual-core
Video Output	HDMI
Audio Output	HDMI, Optical
USB	Yes
Video Decoding	H.264, MPEG-2, MPEG-4
Resolution	1080p
Power Consumption	25W
