4038501 Rev C Operation 3-9
Setting Up the Amplifier with a Handheld Terminal, Continued
Menu Structures and Operations
The number before each menu name is the menu item number.
Menus and Descriptions
1 General
Submenu1
Submenu2
Actions
11 Fwd Config
111 Fwd Gain
Read-write
Select 40 dB or 32 dB
112 Fwd Bandwidth
Read-write
Select 862 MHz or 1 GHz
12 Rev Config
121 Rev Gain
Read-write
20-28 dB, 0.5 dB step
13 Mounted Modules
131 Transponder
Read-only
Mounted or Not Mounted
132 AGC Module
Read-only
Mounted or Not Mounted
14 Power Supply
141 Remote Supply
Read-only
142 24 VDC
Read-only
143 12 VDC
Read-only
15 Temperature
–
Read-only
1°C step
2 Forward
Submenu1
Submenu2
Actions
21 Fwd Input Att
–
Read-write
Set Fwd input attenuation
0–18 dB, Unit in 0.1 dB, 0.5 dB step
22 Fwd Input EQ
–
Read-write
Set Fwd input EQ
0–18 dB, unit in 0.1 dB, 0.5 dB step
23 Fwd Output Att
–
Read-write
Set Fwd output attenuation
0–11.5 dB, unit in 0.1 dB, 0.5 dB step
24 Fwd Output EQ
–
Read-write
Set Fwd output EQ
0–14 dB, unit in 0.1 dB, 0.5 dB step
25 Power Saving
–
Read-write
Select ON or OFF
Continued on next page
