3-10 Operation 4038501 Rev C
Setting Up the Amplifier with a Handheld Terminal, Continued
Menu Structures and Operations, continued
3 Reverse
Submenu1
Submenu2
Actions
31 Rev Input Att
–
Read-write
Set Rev input attenuation
0–20 dB, unit in 0.1 dB, 0.5 dB step
32 Rev Switch
–
Read-write
Set 0 dB, –6 dB or off
33 Rev Output
ATT
–
Read-write
Set Rev output attenuation
0–18 dB, unit in 0.1 dB, 0.5 dB step
34 Rev Output EQ
–
Read-write
Set Rev output EQ
0–15 dB, unit in 0.1 dB, 0.5 dB step
4 Copy Parameters
Submenu1
Submenu2
Actions
41 From Product
411 Setting 1
Nine amplifier settings can be
configured.
If a setting position is available, it
displays Empty; If not available, it
displays nothing.
Copy the parameters from one product
and store those parameters into a
handheld EEPROM. (Parameters for
both AGC module and Amplifier)
Select AMP, AMP+AGC, or Not Exist
(Abort or Execute)
412 Setting 2
413 Setting 3
414 Setting 4
415 Setting 5
416 Setting 6
417 Setting 7
418 Setting 8
419 Setting 9
42 To Product
421 Setting 1
Select and copy a setting to product.
If no valid setting exists, you cannot
enter the menu and No Data displays.
Restore the parameters from a
Handheld EEPROM to a product.
(Parameters for both AGC module and
Amplifier)
Select AMP, AMP+AGC, or Not Exist
(Abort or Execute)
422 Setting 2
423 Setting 3
424 Setting 4
425 Setting 5
426 Setting 6
427 Setting 7
428 Setting 8
429 Setting 9
43 Restore Default
–
Restore the default configuration to a
product. (Parameters for both AGC
module and amplifier)
Select Abort, AMP, AGC, or
AMP+AGC
Continued on next page
