4038501 Rev C Operation 3-11
Setting Up the Amplifier with a Handheld Terminal, Continued
Menu Structures and Operations, continued
5 Identification
Submenu1
Submenu2
Actions
51 Model No
–
Read-only
Displays product model number
52 Serial No
–
Read-only
Displays product serial number
53 Time in Service
–
Read-only
Displays service time, Unit in days
54 Software ID
–
Read-only
Displays amplifier software ID
55 Terminal SW ID
–
Read-only
Displays handheld software ID
56 Product Date
–
Read-only
Displays product date of amplifier
57 HW Version
–
Read-only
Displays hardware version of
amplifier
6 TP Module
Submenu1
Submenu2
Actions
61 TP SW ID
–
Read-only (only when using HMS)
62 MAC ADDR
–
Read-only
63 IP ADDR
–
Read-write (only when using HMS)
Set IP address
64 MASTER RESET
–
Read-write
Select Abort or Reset
65 FREQ
651 STATUS
Read-only
652 FREQ SCAN
Read-write (only when using HMS)
Select Disable or Enable
653 BAUDRATE
Read-write (only when using SMC)
Select 9600, 19200, 38400 or ERROR
654 TX FREQ
Read-write
5–65 MHz, unit in 0.01 MHz
655 RX FREQ
Read-write
45–174 MHz, unit in 0.01 MHz
656 TX LEVEL
Read-write
24–50 dB, unit in 1 dB
657 RX LEVEL
Read-only (only when using HMS)
Note: This menu is only accessible when a transponder is mounted. Same with existing menu in
handheld through LCI interface on transponder.
Continued on next page
