Setting Up the Amplifier with a Handheld Terminal, Continued
Menu Structures and Operations, continued
7 AGC
Module
Submenu1
Submenu2
Actions
71 Pilot Settings
711 Pilot Hi Freq
Read-write
Pilot High Frequency, 47-1002 MHz, Unit in 0.0001
MHz
712 Pilot Hi Level
Read-write
Pilot High Level, 85-120 dBV, Unit in 0.1 dBV
713 Pilot Lo Freq
Read-write
Pilot Low Frequency, 47-1002 MHz, Unit in 0.0001
MHz
714 Pilot Lo Level
Read-write
Pilot Low Level, 85-120 dBV, Unit in 0.1 dBV
72 Bk Pilot
Settings
722 Bk PilotHi Freq
Read-write, Backup Pilot High Frequency, 47-1002
MHz, Unit in 0.0001 MHz
723 Bk PilotHi
Level
Read-write, Backup Pilot High Level, 85-120 dBV,
Unit in 0.1 dBV
725 BkPilot Lo Freq
Read-write, Backup Pilot Low Frequency, 47-1002
MHz, Unit in 0.0001 MHz
726 BkPilotLo Level
Read-write, Backup Pilot Low Level, 85-120 dBV,
Unit in 0.1 dBV
73 Temp Backoff
–
Read-write
-20 deg-C, -10 deg-C, 0 deg-C, 10 deg-C, 20 deg-C,
30 deg-C, 40 deg-C, 50 deg-C, 60 deg-C or AUTO
74 Function
–
Read-write
AA, AGC, FixGain, Standby, ! AA, ! AGC,
! FixGain or ! Standby
In case of alarms, flashing an exclamatory mark “!”
in “! AA/! AGC/! FGain/! Standby”
75 Alarm
–
Read-only
Normal, AA Time Out, AA OutRange, AGC
OutRange or PltLevOutRng
76 Pilot Display
761 Hi Pilot Slt
Read-only
Main/Backup
762 Lo Pilot Slt
Read-only
Main/Backup
763 Active Hi Freq
Read-only
Frequency unit in 0.0001 MHz
764 Active Hi Level
Read-only
Level unit in 0.1 dBV
765 Active Lo Freq
Read-only
Frequency unit in 0.0001 MHz
766 Active Lo Level
Read-only
Level unit in 0.1 dBV
77 Identification
771 Model Number
Read-only
Displays AGC model number
772 Serial Number
Read-only
Displays AGC serial number
773 Software ID
Read-only
Displays AGC software ID
