Figure 3: ASA 5508-X and ASA 5516-X Console Port Connection

Mini USB Type B to USB Type

A console cable

2Mini USB Type B console port1

USB Type A3

Step 4 Connect the end of the cable with the DB-9 connector (or USB Type A) to the terminal or PC. If your terminal or PC has

a console port that does not accommodate a DB-9 connector, you must provide an appropriate adapter for that port.

The LED for the console port turns green and within a few moments the Found New Hardware Wizard appears.

Step 5 Follow the instructions to complete the driver installation.

Step 6 To communicate with the ASA, start a terminal emulator application. This software should be configured with the

following parameters:

• 9600 baud

• 8 data bits

• no parity

• 1 stop bit

• no flow control

Connect to the Console Port with Mac OS X

Follow these steps to connect a Mac OS X system USB port to the console using the built-in OS X Terminal

utility, or alternatively you can use a separate terminal emulator application.

Mount and Connect

Connect to the Console Port with Mac OS X
