Cisco ASA 5545-X Hardware Installation Guide

About This Guide
Where to Find Safety and Warning Information
Cisco ASA 5512-X, ASA 5515-X, ASA 5525-X, ASA 5545-X, and ASA 5555-X Hardware Installation Guide
6
Compliance with Local and National Electrical Codes Warning
Warning: Installation of the equipment must comply with local and national electrical codes. Statement 1074
TN Power Warning
Warning: The device is designed to work with TN power systems. Statement 19
Multiple Power Cords
Warning: This unit has more than one power cord. To reduce the risk of electric shock when servicing a unit,
disconnect the power cord of the power strip into which the unit is plugged. Statement 137
Circuit Breaker (15A) Warning
Warning: This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure
that a fuse or circuit breaker no larger than 120 VAC, 15A U.S. (240 VAC, 10A international) is used on the
phase conductors (all current-carrying conductors). Statement 13
48 VDC Power System
Warning: The customer 48-volt power system must provide reinforced insulation between the primary AC
power and the 48 VDC output. Statement 128
Grounded Equipment Warning
Warning: This equipment is intended to be grounded. Ensure that the host is connected to earth ground
during normal use. Statement 39
Safety Cover Requirement
Warning: The safety cover is an integral part of the product. Do not operate the unit without the safety cover
installed. Operating the unit without the cover in place will invalidate the safety approvals and pose a risk of
fire and electrical hazards. Statement 117
Where to Find Safety and Warning Information
For safety and warning information, see the Regulatory Compliance and Safety Information document at the
following URL:
http://www.cisco.com/c/en/us/td/docs/security/asa/hw/regulatory/compliance/asa5500x_rcsi.html
This RCSI document describes the international agency compliance and safety information for the
Cisco ASA 5500-X series. It also includes translations of the safety warnings used in this guide.
Related Documentation
For a complete list of the Cisco ASA 5500-X series documentation and where to find it, see the documentation
roadmap at the following URL:
http://www.cisco.com/en/US/docs/security/asa/roadmap/asaroadmap.html

Cisco ASA 5545-X Specifications

General

Power Supply	Dual, Hot-swappable
Memory	8 GB
Flash Memory	8 GB
AC Input Voltage	100-240 VAC
Form Factor	1 RU
Number of VLANs	1024
Security Contexts	50
Interfaces	8 x Gigabit Ethernet
Frequency	50-60 Hz
Dimensions (H x W x D)	1.75 x 17.5 x 12 in (4.4 x 44.5 x 30.5 cm)
High Availability	Active/Standby
Storage	SSD (optional)
