Identifying Cable Pinouts

Gigabit and Fibre Channel Ports

Cisco ASA 5512-X, ASA 5515-X, ASA 5525-X, ASA 5545-X, and ASA 5555-X Hardware Installation Guide

Gigabit and Fibre Channel Ports

Table 4 lists the types of SFP modules and connectors used in the ASA.

Table 5 lists the SFP port cabling specifications for the SFP modules and connectors used in the ASA.

TP1- 5

TP3+ 7

TP3- 8

Table 3 10/100/1000BASE-T Management Port Cable Pinouts (MDI)

Signal Pin

Table 4 Types of SFP Modules and Connectors

Port Compliance Connector Fiber Type

Gigabit Ethernet 1000BASE-SX SW MMF

1000BASE-LX LW SMF

Table 5 SFP Port Cabling Specifications

Cisco Product

Number

Wavelength

(nanometer)

Core Size

(micron)

Baud

Rate

Cable

Distance

GLC-SX-MM= 850 62.5

50.0

1.0625

300 m

500 m

GLC-LH-SM= 1300 9.0 1.0625 10 km
