Cisco ASA 5512-X, ASA 5515-X, ASA 5525-X, ASA 5545-X, and ASA 5555-X Hardware Installation Guide
10
ASA 5512-X, ASA 5515-X, or ASA 5525-X
ASA 5545-X and ASA 5555-X
Internal and External USB Flash Drives
The Cisco ASA 5500-X has internal and (optional) external USB drives.
 Internal USB Drive, page 11
1
3 4
2
330545
76
5
1 ASA 5512-X, ASA 5515-X, or ASA 5525-X
Chassis
2 Blue Console Cable and Serial PC Terminal
Adapter (DB-9 to RJ-45)
3 Power Cord 4 Power Cord Retainer
5 4 10-32 Phillips Screws for rack mounting 6 4 12-24 Phillips Screws for rack mounting
7 4 M6 Phillips Screws for rack mounting
330544
1
3
2
4
5
1 ASA 5545-X or ASA 5555-X Chassis
(one power supply shown)
2 Blue Console Cable and Serial PC Terminal
Adapter (DB-9 to RJ-45)
3 Power Cord 4 Power Cord Retainer
5 Rack-Mount Bracket Kit
