7) UID0, UID1 to be set to user’s PIN. Don’t use same PIN for both.
8) Keep PWD0, PWD1 blank. You will see a black dot in this field if it is set blank.
9) GkOrProxy to be set to 202.54.117.212.
10) Set UseLoginID to 1. (for 3.1.x SIP image In case you face a problem in getting registered/dial tone & making a call, try with
value “0” in place of “1”)
11) Make LoginID0, LoginID1 same as UID0 and UID1 respectively.
12) GkId is to be specified: in our case it is NexgeGK. (in case you are using a 3.1.x SIP image , this field won’t be there &
hence ignore it)
13) UseSIP is set to 1 if your ATA is having image V2.16 or 2.15 which supports both SIP & H.323. If your ATA is having image
V3.1.x which supports only SIP then you don’t need to bother about this parameter as it won’t be there.
14) SIPRegOn is to be made 1.
15) DNS1IP & DNS2IP to be set to 202.54.1.30 & 202.54.1.18 respectively if it is on public IP, else you
can use the customer’s own
DNS server IP for the same.
16) Make sure that LBRCodec, RxCodec, TxCodec are set to 0.
17) Make sure ConnectMode is set to 0x00060401.
18) Set “Polarity” to “0x00000001 “ (this is required if you are connecting a billing maching to the ATA for billing like the
way it is done in PCO/STD/ISD booth)
19) Leave all other fields to their default value.
After entering these values, click on the “Apply” button at the bottom and then “Click here to reload” button at the top to update
the website with these settings.
A sample of how the website looks is given below (please note that you have to enter data specific to your device for correct
configuration):
Cisco ATA with image V3.1.x(SIP)
Cisco ATA 186 (SIP) Configuration
ata000d6508e9ab
Version: v3.1.0 atasip (Build 040211A)
MAC: 0.13.101.8.233.171
SerialNumber: INM072861V6
ProductId: ATA186I1
To Next Page
Loading...
