APPENDIX B
Connector and Cable Specifications
This appendix contains these topics:
• Connector Specifications, on page 51
• Cables and Adapters, on page 52
Connector Specifications
10/100/1000 Ports (Including PoE)
All 10/100/1000 ports use standard RJ-45 connectors and Ethernet pinouts.
Figure 35: 10/100/1000 Port Pinouts
SFP Module Connectors
Figure 36: Duplex LC Cable Connector
Cisco Catalyst 1000 Series 8-Port and 16-Port Switch Hardware Installation Guide
51
