40
Cisco Catalyst 9130AX Series Access Points
Operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to
co-channel mobile satellite systems.
La bande 5 150-5 250 MHz est réservés uniquement pour une utilisation à l'intérieur afin de réduire les risques de
brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.
Users are advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350
MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
Les utilisateurs êtes avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux
(c.-à-d., qu'ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer
du brouillage et/ou des dommages aux dispositifs LAN-EL.
Table 4 List of Internal Antennas Supported on C9130AXI
Antenna Type Antenna Gain Antenna Impedance
Single-Port Single-Band Omni (VPOL)
BLE/IOT
4 dBi 50 ohms
Single-Port Dual-Band Omni (VPOL)
AUX
2.4 GHz—4.5 dBi
5 GHz—6 dBi
50 ohms
Single-Port Single-Band Omni (HPOL)
Slave
5 GHz—6dBi 50 ohms
Single-Port Single-Band Omni (HPOL)
Slave
5 GHz—6dBi 50 ohms
Single-Port Single-Band Omni (HPOL)
Slave
5 GHz—6dBi 50 ohms
Single-Port Single-Band Omni (HPOL)
Slave
5 GHz—6dBi 50 ohms
Single-Port Dual-Band Omni (VPOL)
Master
2.4 GHz—4 dBi
5 GHz—6 dBi
50 ohms
Single-Port Dual-Band Omni (VPOL)
Master
2.4 GHz—4 dBi
5 GHz—6 dBi
50 ohms
Single-Port Dual-Band Omni (VPOL)
Master
2.4 GHz—4 dBi
5 GHz—6 dBi
50 ohms
Single-Port Dual-Band Omni (VPOL)
Master
2.4 GHz—4 dBi
5 GHz—6 dBi
50 ohms
Table 5 List of External Antennas Supported on C9130AXE
Part Number Description Gain
C-ANT9101= Ceiling Mount Omni Self-Identifying Antenna with
Bluetooth, 8-port, with DART connectors.
2 dBi (2.4 GHz)
6 dBi (5 GHz)
3 dBi (BLE)
C-ANT9102= Pole or Wall Mount Omni Self-Identifying Antenna
with Bluetooth, 8-port, with DART connectors.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
4 dBi (BLE)
C-ANT9103= Pole or Wall mount 75° Directional Self-Identifying
Antenna with Bluetooth, 8-port, with DART
connectors.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
6 dBi (BLE)
AIR-ANT2513P4M-N= Patch Antenna, 4-port, with N connectors.
Note Connect to AP using AIR-CAB003-D8-N =.
13 dBi (2.4 GHz)
13 dBi (5 GHz)
13 dBi (BLE)
