Cisco Catalyst 9130AX Series Access Points
Note When using the breakout cables and connecting to legacy dual band antennas, the BLE radio will experience
the gain of that antenna at 2.4 GHz.
AIR-ANT2524V4C-R= Ceiling Mount Omni Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
2 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2524V4C-RS= Ceiling Mount Omni Self-Identifying Antenna, 4-port,
with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
2 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2544V4M-R= Wall Mount Omni Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2544V4M-RS= Wall Mount Omni Self-Identifying Antenna, 4-port,
with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
4 dBi (2.4 GHz)
4 dBi (5 GHz)
AIR-ANT2566D4M-R= 60° Patch Antenna, 4-port, with RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
AIR-ANT2566D4M-RS= 60° Patch Self-Identifying Antenna, 4-port, with
RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
AIR-ANT2566P4W-R= Directional Antenna, 4-port, with RP-TNC
connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
AIR-ANT2566P4W-RS= Directional Self-Identifying Antenna, 4-port, with
RP-TNC connectors.
Note Connect to AP using AIR-CAB002-D8-R=.
6 dBi (2.4 GHz)
6 dBi (5 GHz)
Table 5 List of External Antennas Supported on C9130AXE
Part Number Description Gain

Cisco C9130AXI Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Antenna Type	Internal Antennas
Product Type	Wireless Access Point
Form Factor	Ceiling Mountable
Wireless Standard	802.11ax
Operating Temperature	0°C to 40°C (32°F to 104°F)
Mounting	Ceiling, Wall
USB Port	1 x USB 2.0
Frequency Bands	2.4 GHz, 5 GHz
Power Options	802.3at PoE+
Maximum Data Rate	4.8 Gbps
Weight	1.2 kg
MIMO Configuration	8x8:8 MU-MIMO (5 GHz), 4x4:4 MU-MIMO (2.4 GHz)
