Cisco C9130AXI Series User Manual

9
Cisco Catalyst 9130AX Series Access Points
5 AP View s, Ports, and Connectors
Figure 1 Face of the 9130AXI M odel
1
Status LED
3
USB 2.0 port
2
Location of the ports and connectors on the head of the
AP.

Cisco C9130AXI Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Antenna Type	Internal Antennas
Product Type	Wireless Access Point
Form Factor	Ceiling Mountable
Wireless Standard	802.11ax
Operating Temperature	0°C to 40°C (32°F to 104°F)
Mounting	Ceiling, Wall
USB Port	1 x USB 2.0
Frequency Bands	2.4 GHz, 5 GHz
Power Options	802.3at PoE+
Maximum Data Rate	4.8 Gbps
Weight	1.2 kg
MIMO Configuration	8x8:8 MU-MIMO (5 GHz), 4x4:4 MU-MIMO (2.4 GHz)
