Cisco Catalyst 2900 Series Hardware Installation Guide

Chapter 2 Installation
Installing a Module
2-4
Catalyst 2900 Series XL Modules Hardware Installation Guide
78-5912-03
Step 3 Slide the module into the slot card-guides until you feel it touch the back of the
unit.
Step 4 Push the module firmly until it snaps into place.
Step 5 Tighten the thumbscrews on the module faceplate. The module begins running
POST when the thumbscrews are tightened.
Note The installation is not complete until the thumbscrews are
tightened.
Step 6 Ensure that the STATUS LED is green (module operational).
Step 7 If the module is not operational, reseat it. If the module still is not operational,
contact Cisco Systems for a replacement.
Handling a GBIC
Following are the Gigabit Interface Converter (GBIC) handling guidelines:
• GBICs are static sensitive. To prevent ESD damage, follow appropriate board
and component handling procedures.
• GBICs are dust sensitive. When storing a GBIC or when a fiber-optic cable is
not plugged in, always keep plugs in the GBIC optical bores.
• The most common source of contaminants in the optical bores is debris
picked up on the ferrules of the optical connectors. Use an alcohol swab or
Kim-Wipe to clean the ferrules of the optical connector.
