Heat sink fins (PoE models only)
Figure 7: Rear Panel of a Non-PoE Switch
A loop (for the optional power cord
retainer)
3Security Slot1
An AC power connector2
Figure 8: Rear Panel of a PoE Switch
A loop (for the optional power cord
retainer)
3Security Slot1
Heat sink fins4An AC power connector2
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
11
Product Overview
Rear Panel
