Uplink port LED ( SFP/SFP+)10PoE LED
5
5
4
Only on switch models that have stacking capability. Note that this release does not support switch stacking.
5
Only on switch models that support PoE.
System LED
System StatusColor
System is not powered on.Off
System is operating normally.Green
System is receiving power but is not operating
properly.
Amber
System StatusColor
System is not powered on.Off
System is operating normally.Green
System is receiving power but is not operating
properly.
Amber
POST is in progress.Blinking Green
Modes for Port LEDs
The port LEDs, as a group or individually, display information about the switch and about the individual
ports.
DescriptionPort ModeLED
The port status. This is the default mode.Port statusSTAT
The port operating speed: 10, 100, or 1000
Mb/s.
Port speedSPEED
The PoE status.PoE port powerPoE
