Data Sheet
© 2010 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 28
Switch Configurations
All switch models can be configured with the optional four GbE or two 10 GbE network module. The switch models
are available with either the LAN Base or IP Base feature set. IP Services feature set is available as an upgrade
option at the time of ordering or through a license at a later time.
Stackable Switches
Figure 1 shows the Cisco Catalyst 3750-X Series Switches (front and back).
Figure 1. Cisco Catalyst 3750-X Series Switches (Front and Back)
Table 1 shows the Cisco Catalyst 3750-X Series configurations.
Table 1. Cisco Catalyst 3750-X Series Configurations
Feature Set Models Total 10/100/1000
Ethernet Ports
Default AC Power
Supply
Available PoE Power StackPower
WS-C3750X-24T-L 24
WS-C3750X-48T-L 48
350W –
WS-C3750X-24P-L 24 PoE+
WS-C3750X-48P-L 48 PoE+
715W 435W
LAN Base
WS-C3750X-48PF-L 48 PoE+ 1100W 800W
Available with upgrade
to IP Base
WS-C3750X-24T-S 24
WS-C3750X-48T-S 48
350W –
WS-C3750X-24P-S 24 PoE+
WS-C3750X-48P-S 48 PoE+
715W 435W
IP Base
WS-C3750X-48PF-S 48 PoE+ 1100W 800W
Yes
Standalone Switches
Figure 2 shows Cisco Catalyst 3560-X Series Switches.
Figure 2. Cisco Catalyst 3560-X Series Switches
Table 2 shows the Cisco Catalyst 3560-X Series configurations.
