Physical Specifications
Table 6 lists physical specifications.
Table 6. Physical Specifications of Cisco Catalyst 4500 Series Chassis
Specification WS-C4503-E WS-C4506-E WS-C4507R+E WS-C4510R+E
Dimensions (H x W x D) 12.25 x 17.31 x 12.50 in.
(31.12 x 43.97 x 31.70 cm)
17.38 x 17.31 x 12.50 in.
(44.13 x 43.97 x 31.70 cm)
19.19 x 17.31 x 12.50 in.
(48.74 x 43.97 x 31.70 cm)
24.35 x 17.31 x 12.50 in.
(61.84 x 43.97 x 31.70 cm)
Rack units (RU) 7RU 10RU 11RU 14RU
Chassis weight (with fan
tray)
32.25 lb (14.63 kg) 40.50 lb (18.37 kg) 44.50 lb (20.19 kg) 54.50 lb (24.73 kg)
Mounting 19- and 23-in. rack
compatible (19-in. rack and
cable guide hardware
included)
19- and 23-in. rack
compatible (19-in. rack and
cable guide hardware
included)
19- and 23-in. rack
compatible (19-in. rack and
cable guide hardware
included)
19- and 23-in. rack
compatible (19-in. rack and
cable guide hardware
included)
Power Supply Indicators and Interfaces
●
Output Fail LED (per unit): RED
●
Input OK LED(per input): Green
●
Fan OK LED(per input): Green
Tables 7 and 8 describe power supply specification.
Table 7. Cisco Catalyst 4500E Series Power Supply Specifications (Data Only)
Power Supply 1000W AC 1400W AC 1400W DC Triple Input
Integrated PoE No (data only) No (data only) No (data only)
Input current (rated) 12A at 100 VAC, 5A at 240 VAC 16A at 100 VAC, 7A at 240 VAC Two -48 VDC at 15A;
One -48 VDC at 12.5A
Output current (data)
●
12V at 83.4A
●
3.3V at 12.2A
●
12V at 113.4A
●
3.3V at 12.2A
●
12V at 1360W
●
3.3V at 40W
Output power redundant mode (data) 1000W + 40W 1360W + 40W 1400W + 40W
Output power combined mode (data) 1667W 2473W -
Heat dissipation 943 Btus per hour 1048 Btus per hour 1048 Btus per hour
Holdup time 20 ms 20 ms 8 ms
Hot-swappable Yes Yes Yes
Table 8. Cisco Catalyst 4500E Series Power Supply Specifications (Data and PoE)
Power Supply 1300W AC 2800W AC 4200W AC 6000 AC 9000 AC 1400W DC with Power Entry
Module (PEM)
Integrated PoE Yes
(up to 800W)
Yes
(up to 1400W)
Yes
(up to 3855W)
Yes
(up to 4800W)
Yes
(up to 7500W)
Up to 7500W (minus the power
consumed for data) when
connected directly to a DC power
plant or 2 external AC power
shelves
Input current
(rated)
●
16A at 100
VAC
●
7A at 240
VAC
●
16A at 200
VAC
●
Two 12A at
100 VAC
Or
●
Two 12A at
200 VAC
●
Two 12A at
100 VAC
Or
●
Two 16A at
200 VAC
●
Three 12A
at 100 VAC
Or
●
Three 16A
at 200 VAC
●
31A at -60 VDC (data only)
●
180A at -48 VDC (PoE)
Output current
(data)
●
12V at
84.7A
●
3.3V at
12.5A
●
12V at
113.3A
●
3.3V at
12.5A
●
12V at
115.3A
●
3.3V at
12.5A
●
12V at
186.9A
●
3.3V at
12.5A
●
12V at
163.3A
●
3.3V at
12.5A
●
12V at 120A
●
3.3V at 12.5A
