Cisco Catalyst 4500 Series User Manual

Switch
Console
(DTE)
RJ45-to-RJ45
Rollover Cable
RJ45-to-DB25
Adapter
Terminal
(DTE)
Signal
RJ45
Pin
RJ45
Pin
DB25 Pin Signal
RTS 1¹ 8 5 CTS
DTR 2 7 6 DSR
TxD 3 6 3 RxD
GND 4 5 7 GND
GND 5 4 7 GND
TxD 6 3 2 TxD
DSR 7 2 20 DTR
CTS 8¹ 1 4 RTS
¹Pin 1 is connected internally to Pin 8.
Configuring a Terminal for Attachment to the Console or RSFC Port
Note: The console port is an asynchronous (Async) serial port; any device connected to this port must be
capable of asynchronous transmission.
Before connecting the console port, check the terminal documentation to determine the baud rate. The
baud rate of the terminal must match the default baud rate (9600 baud) of the console port. Set up the
terminal as follows:
9600 baud
●
8 data bits●
No parity●
1 stop bit●
Connecting a Terminal to the Catalyst 4000
Supervisor Engine I Console Port
The console port, shown in the figure below, is a data communications equipment (DCE) DB-25
receptacle that supports a DCE EIA/TIA-232 interface. EIA/TIA-232 supports unbalanced circuits at
signal speeds up to 64 kbps.
Figure: DCE DB-25 Connector
Cisco - Connecting a Terminal to the Console Port on Catalyst Switches
http://www.cisco.com/warp/public/473/9.html (13 of 19) [9/4/2003 12:36:03 PM]

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
