Cisco Catalyst 4503-E User Manual

Cisco Cat4K NDPP ST 11 March 2014
EDCS-1228241
16
Feature
Cisco Catalyst
WS-C4503-E
Chassis
Cisco Catalyst
WS-C4506-E
Chassis
Cisco Catalyst
WS-C4507R+E
Chassis
Cisco Catalyst
WS-C4510R+E
Chassis
Location of 23-
inch rack mount
Front (option)
Front (option)
Front (option)
Front (option)
Cisco Catalyst 4500 Series line cards can be mixed and matched to suit numerous LAN
access, server connectivity, or branch-office deployments. The Cisco Catalyst 4500
Series supports the following supervisor and line cards, by product number:
Table 6 Catalyst 4500 Series Switch Chassis Line Cards
Product Number /Description
Cisco Catalyst 4500E Supervisor Cards
Supervisor Engine 7-E
• Performance and capability
– 848 Gbps switching capacity with 250 Mpps of throughput
– 4 nonblocking 10 Gigabit Ethernet uplinks (Small Form-Factor
Pluggable Plus [SFP+])
– SFP support on uplinks to offer flexibility for up to 4 Gigabit
Ethernet ports
– 384 ports of nonblocking 10/100/1000
– PoEP (30W) capabilities on all ports in a line card simultaneously
– UPOE (60W) capabilities on all line-card slots
– Energy Efficient Ethernet (IEEE 802.3az)
– 196 ports of nonblocking Gigabit Ethernet SFP
– 100 ports of 10 Gigabit Ethernet SFP+ (4 uplinks ports + 96 line-
card ports)
– 128,000 FNF entries in hardware
– External USB and Secure Digital (SD) card support for flexible
storage options
– 256,000 routing entries for high-end campus access and
aggregation deployments
– IPv6 support in hardware, providing wire-rate forwarding for IPv6
networks
– Dynamic hardware forwarding-table allocations for ease of IPv4-
to-IPv6 migration
– Scalable routing (IPv4, IPv6, and multicast) tables, Layer 2 tables,
