C-41
Catalyst 4900 Series Switch Installation Guide
78-18039-02
Appendix C Compliance Information and Translated Safety Warnings
Regulatory Standards Compliance
Qwest NEBS
Compliance
TCG Checklist
ATT NEBS requirements ATT TP76200 level 3 and TCG Checklist
ETSI ETS 300 019-2-1, Class 1.1 Storage
ETS 300 019-2-2, Class 2.1 and 2.2 Transportation
ETS 300 019-2-3, Class 3.1E Stationary Use
Ta b l e C-3 GR-1089 Installation and Caution Instructions
Shielded cable grounded at both ends specified for copper telecom ports.
Caution The intra-building port(s) of the equipment or subassembly is suitable
for connection to intra-building or unexposed wiring or cabling only.
The intra-building port(s) of the equipment or subassembly must not
be metallically connected to interfaces which connect to the OSP or
its wiring. These interfaces are designed for use as intra-building
interfaces only (Type 2 or Type 4 ports as described in
GR-1089-CORE, Issue 4) and require isolation from the exposed OSP
cabling. The addition of primary protectors is not sufficient
protection in order to connect these interfaces metallically to OSP
wiring.
The Catalyst 4900 Series Switches have AC power ports that are intended for
deployments where an external Surge Protective Device (SPD) is utilized at the
AC power service equipment (see definition in National Electric Code).
The Catalyst 4900 Series Switches are designed for a Common Bonding
Network (CBN) installation.
The Catalyst 4900 Series Switches can be installed in network
telecommunication facilities or locations where the National Electric Code
applies.
Table C-2 Industry EMC, Safety, and Environmental Standards
(continued)
Specification Standard
To Next Page
