DescriptionColor/StateLED
Power supply is failed.YellowOK
The power supply needs attention, activated
for events like high temperature, high power
or slow fan.
Blinking yellowOK
Rear Panel
Figure 11: Rear Panel
Fan trays1
Catalyst 6840-X Switch Series Hardware Installation Guide
21
Product Overview
Rear Panel
