CHAPTER 2
Hardware Features
This section describes the following hardware features of the C9124AXI-x and C9124AXD-x models:
• Access Point Views, Ports, and Connectors, on page 5
• C9124AXI (Internal Antenna) Model: Antenna Radiation Patterns, on page 7
• C9124AXD (Directional Antenna) Model: Antenna Radiation Patterns, on page 10
• Power Sources, on page 12
Access Point Views, Ports, and Connectors
Cisco Catalyst 9124AX Series Outdoor AP has multiple options that you can use to power the AP or join the
AP to the controller. Section Connectors and Ports, on page 5 show the connectors and ports for C9124AXI
and C9124AXD models.
The illustrations in this document show all the available connections for the AP. Unused connections are
capped with a connector plug to ensure the watertight integrity of the AP. Liquid-tight adapters are provided
for connector openings. You can install the adapters before or after deploying the AP.
Note
Connectors and Ports
The following illustrations show the different connector and port options available on the base and sides of
the AP.
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
5
