Cisco Catalyst 9130AX Series Access Points
Figure 2 Ports and Connectors on the Head of the C9130AXI Model
1
Kensington lock slot
4
RJ-45 console port
2
Security hasp for padlocking AP to mounting bracket
5
5 GbE port
3
Mode button
For information on how to use the Mode button, see
“Using
the Mode Button”
section.
6
USB 2.0 port

Cisco Catalyst 9130AX Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Bluetooth	Bluetooth 5.0
Target Wake Time (TWT)	Yes
BSS Coloring	Yes
USB Port	1x USB 2.0
Frequency Bands	2.4 GHz, 5 GHz
PoE	802.3at (PoE+)
Antenna Type	Internal
OFDMA	Yes
Mounting	Ceiling, Wall
Weight	1.2 kg
Security	WPA3, WPA2, WPA, 802.1X
Management	Cisco DNA Center, Cisco Prime Infrastructure
MIMO	8x8:8 MU-MIMO (5 GHz), 4x4:4 MU-MIMO (2.4 GHz)
