Cisco Catalyst 9130AX Series Access Points
Figure 3 Face of the C9130AXE Model
1
Location of the Smart Antenna connector port under yellow cap
1
1. Only external antennas with the 8-port DART cable can be connected to this AP.
3
Status LED
2
Location of the ports on the head of the AP.
4
USB 2.0 port
