Cisco Catalyst 9164 Series - CW9164 I (Internal Antenna) Radiation Patterns

CW9164I Top View
Figure 2: CW9164I Top View with Connectors and Ports
RJ-45 console port5Kensington lock slot1
2.5GbE port6Security hasp for
padlocking AP to
mounting bracket
2
DC 54V power input port7Environment Sensor vents3
USB 2.0 port8Mode button
For information on how
to use the Mode button,
see the
Using the Mode Button
section
4
CW9164I (Internal Antenna) Radiation Patterns
The following illustrations show the CW9164I model with internal antenna radiation patterns:
