Mounting the Switch in a Rack
Procedure
Step 1 Use the four supplied Phillips machine screws to attach the brackets to the rack.
Step 2 Use the black Phillips machine screw to attach the cable guide to the left or right bracket.
Figure 16: Front-Mounting Position
Number-12 or number-10 Phillips machine
screws
3Phillips machine screw, black1
--Cable guide2
Figure 17: Mid-Mounting Position
Installing a Switch
14
Installing a Switch
Mounting the Switch in a Rack
