Figure 8: Front View of the C9400-LC-24XS Switching Module
Captive installation screws5STATUS LED1
Ejector levers6LOCATE (blue beacon) LED2
Model or product number7PORT LINK LED for the port in the top row3
Switching module Radio Frequency Identifier (RFID)4
