Cisco Catalyst C9200CX-12P-2X2G - Front Panel Components

• USB Type A storage port
• USB micro-Type B console port
• LEDs
• Blue Beacon
• SD card slot
• Internal power supply connector for compact switches
Front Panel of a C9200CX-12P-2X2G Switch
2x10G SFP+ uplink ports7SD Card slot1
Internal power supply connector8SD Card security lock2
USB Type A connector9Blue Beacon3
Mode button10Status LEDs4
USB micro-Type B (console) port1110/100/1000 PoE+ ports5
--2x1G copper uplink ports6
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
2
Product Overview
Front Panel Components
