Figure 13: Mounting the Switch Under a Desk or Shelf
--Two 10-32 Phillips pan-head screws1
Figure 14: The Switch in Installed Position
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
33
Installing a Compact Switch
Mounting Under a Desk or a Shelf
