Cisco Catalyst C9200L-24PXG-4X-E Installation Guide

CHAPTER 5
Installing a Fan Module
• Fan Modules Overview , on page 47
• Installation Guidelines, on page 48
• Installing a Fan Module, on page 48
• Finding the Fan Module Serial Number, on page 49
Fan Modules Overview
Cisco Catalyst 9200 (C9200) Series switches support two field-replaceable fan modules providing N+1
redundancy support. The switch should be able to operate at ambient temperature if one of the fans fails.
Figure 31: Fan Module
Retainer clip3Extraction handles1
Fan LED2
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
47
